Area scan cameras Hikrobot

Hikrobot area scan cameras for inspection, verification and measurement: GigE and USB interfaces, 1.3 to 12+ MP, global and rolling shutter options.

ModelResolutionFrame rateSensorInterface
MV-CS016-10GMArea camera1440 × 1080 px65.2 fps1/2.9″Gigabit Ethernet, compatible with Fast Ethernet
MV-CS050-10GMArea camera2448 × 2048 px24.2 fps2/3″Gigabit Ethernet, compatible with Fast Ethernet
MV-CH120-60UCArea camera4096 × 300030.7 fps1.1″USB 3.0, compatible with USB 2.0
MV-CU120-10GMArea camera4024 × 3036 px9.7 fps1/1.7″Gigabit Ethernet
MV-CA013-A0GMArea camera1280 × 1024 px92.8 fps1/2″Gigabit Ethernet
MV-CS050-10GCArea camera2448 × 2048 px24.2 fps2/3″Gigabit Ethernet, compatible with Fast Ethernet
MV-CS060-10GMArea camera3072 × 2048 px19.1 fps1/1.8″Gigabit Ethernet
MV-CH6040-10XM-M72-NFArea scan camera28416 × 21280 px1.45 fps @ 28416 × 21280 Mono 8; 1.38 fps @ 14208 × 10264 RGB 866.7 mmCoaXPress with DIN interface
MV-CH800-60TM-M58S-NNArea camera10304 × 7712 px15 fps30 × 22.4 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CU020-90UMArea camera2048 × 1200 px150.2 fps1/1.7″USB3.0, compatible with USB2.0
MV-CH050-10CMArea camera2432 × 2048140 fps @2432 × 20482/3″Camera Link with SDR interface
MV-CH650-90XM-F-NFArea camera9344 × 7000 px31.5 fps29.9 × 22.4 mmCoaXPress with DIN interface
MV-CS200-10GCArea camera5472 × 3648 px5.9 fps1″Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CE120-10GCArea camera4024 × 3036 px9.6 fps1/1.7″Gigabit Ethernet, compatible with Fast Ethernet
MV-CH310-10TC-M58S-NNArea camera6464 × 4852 px17.2 fps22.3 × 16.7 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CH123-10UCArea camera4096 × 3000 px31.5 fps1/1.1″USB 3.0, compatible with USB 2.0
MV-CH050-90XM-C-NNArea camera2592 × 2160 px213 fps @2592 × 2160 Mono 81/2″CoaXPress with DIN interface
MV-CH500-90TC-M58S-NFArea scan camera7008 × 700015.5 fps @ 7008 × 700022.4 mm × 22.4 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CH250-25TM-M58S-NFArea camera5120 × 512040 fps @ 5120 × 512023 × 23 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CH800-60TC-M58S-NNArea camera10304 × 7712 px15 fps30 × 22.4 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CH1030-90TC-M58S-NNArea camera11264 × 920011 fps46.6 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CH250-90TC-C-NFArea scan camera5120 × 5120 px41.5 fps @ 5120 × 51201.1″10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CA016-10UCArea camera1440 × 1080 px249.1 fps1/2.9″USB3.0, compatible with USB2.0
MV-CA013-20GCArea camera1280 × 1024 px90 fps1/2″Gigabit Ethernet
MV-CA003-20GCArea camera672 × 512 px336 fps1/4″Gigabit Ethernet, compatible with Fast Ethernet
MV-CA017-10GMArea camera1608 × 1104 px68.5 fps1.1″Gigabit Ethernet
MV-CA023-10GMArea camera1920 × 1200 px41 fps1/1.2″Gigabit Ethernet, compatible with Fast Ethernet
MV-CA050-12GCArea camera2448 × 2048 px24.1 fps2/3″Gigabit Ethernet, compatible with Fast Ethernet
MV-CE013-80UMArea camera1280 × 1024 px148 fps1/2.7″USB3.0, compatible with USB2.0
MV-CE050-30UCArea camera2592 × 1944 px44.7 fps1/2.5″USB3.0, compatible with USB2.0
MV-CE060-10UMArea camera3072 × 2048 px42.7 fps1/1.8″USB3.0, compatible with USB2.0
MV-CE100-30GCArea camera3840 × 2748 px7 fps1/2.3″Gigabit Ethernet, compatible with Fast Ethernet
MV-CE120-10GMArea camera4024 × 3036 px9.6 fps1/1.7″Gigabit Ethernet
MV-CE200-10GMArea camera5472 × 3648 px5.9 fps1″Gigabit Ethernet
MV-CS004-10GMArea camera720 × 540 px125.2 fps1/2.9″Gigabit Ethernet
MV-CS004-10UMArea camera720 × 540 px526.5 fps1/2.9″USB3.0, compatible with USB2.0
MV-CS016-10UMArea camera1440 × 1080 px249.1 fps1/2.9″USB3.0, compatible with USB2.0
MV-CS020-10GMArea camera1624 × 1240 px60 fps1/1.7″Gigabit Ethernet, compatible with Fast Ethernet
MV-CS020-10UMArea camera1624 × 1240 px—1/1.7″USB 3.0, compatible with USB 2.0
MV-CS023-10GMArea camera1920 × 1200 px41 fps1/1.2″Gigabit Ethernet
MV-CS028-10UMArea camera1936 × 1464 px132.2 fps2/3″USB3.0, compatible with USB2.0
MV-CS032-10GMArea camera2048 × 1536 px38.1 fps1/1.8″Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CS050-10UMArea camera2448 × 2048 px60 fps2/3″USB3.0, compatible with USB2.0
MV-CU004-10GMArea camera720 × 540 px126.5 fps1/2.9″Gigabit Ethernet, compatible with Fast Ethernet
MV-CU013-80GCArea camera1280 × 1024 px89.9 fps1/2.7″Gigabit Ethernet
MV-CU050-60GMArea camera2592 × 1944 px23.1 fps1/2.5″Gigabit Ethernet, compatible with Fast Ethernet
MV-CU060-10GMArea camera3072 × 2048 px19.1 fps1/1.8″Gigabit Ethernet, compatible with Fast Ethernet
MV-CB004-10GM-SArea camera720 × 540 px125.2 fps1/2.9″Gigabit Ethernet, compatible with Fast Ethernet
MV-CB004-10GC-SArea camera720 × 540 px125.2 fps1/2.9″Gigabit Ethernet, compatible with Fast Ethernet
MV-CB013-A0UM-SArea camera1280 × 1024 px201 fps1/2″USB3.0
MV-CB013-A0UC-SArea camera1280 × 1024 px201 fps1/2″USB3.0
MV-CB016-10GM-SArea camera1440 × 1080 px65.2 fps1/2.9″Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CB016-10UC-C V4.0Area camera1440 × 1080 px165.4 fps1/2.9″USB 3.0
MV-CB020-60UM-CArea camera1624 × 1240 px179.9 fps1/2.53″USB 3.0
MV-CB020-60UC-CArea camera1624 × 1240 px179.9 fps1/2.53″USB 3.0
MV-CB050-60UM-C-FArea camera2448 × 2048 px—2/3″USB 3.0, compatible with USB 2.0
MV-CB050-60UC-C-FArea camera2448 × 2048 px—2/3″USB 3.0, compatible with USB 2.0
MV-CB060-10GM-SArea camera3072 × 2048 px19.1 fps1/1.8″GigE
MV-CB060-10GC-SArea camera3072 × 2048 px19.1 fps1/1.8″GigE
MV-CB120-10GM-SArea camera4024 × 3036 px9.7 fps1/1.7″Gigabit Ethernet
MV-CB120-10UM-C V4.0Area camera4032 × 3036 px30 fps1/1.7″USB 3.0
MV-CB120-10UC-C V4.0Area camera4032 × 3036 px30 fps1/1.7″USB 3.0
MV-CH089-10GMArea camera4096 × 2160 px13 fps1″Gigabit Ethernet, compatible with Fast Ethernet
MV-CH089-10UMArea camera4096 × 2160 px32 fps1″USB 3.0, compatible with USB 2.0
MV-CH100-60GMArea camera4096 × 2460 px11.6 fps1″Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CH100-60UMArea camera4096 × 2460 px36 fps1″USB 3.0, compatible with USB 2.0
MV-CH1010-10CM-M72-NFArea camera11648 × 8740 px8.1 fps55 mmCamera Link with SDR interface
MV-CH140-60GMArea camera4708 × 2824 px9 fps1″Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CH140-90YM-M58S-NFArea camera4608 × 3072 px339 fps—CoaXPress with Micro-BNC interface
MV-CH1510-10XM-M72-NFArea camera14208 × 10640 px6.2 fps—CoaXPress with DIN interface
MV-CH1510-11XM-M72-TFArea camera14208 × 10640 px6.2 fps—CoaXPress with DIN interface
MV-CH1520-90GM-M72-NNArea camera16320 × 9200 px——Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CH210-90YM-M58S-NNArea camera5120 × 4096 px222 fps23.04 × 18.43 mmCoaXPress with Micro-BNC interface
MV-CH240-10TM-C-NNArea camera5328 × 4600 px35.1 fps—10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CH2450-10YM-M72-TFArea camera19200 × 12800 px12.4 fps64.84 mmCoaXPress with HDBNC interface
MV-CH320-60TM-M58S-NNArea camera7744 × 4336 px30 fps22.6 × 12.7 mm10 Gigabit Ethernet, compatible with Gigabit Ethernet
MV-CH610-10TM-F-TF V2.0Area camera9568 × 6380 px17.9 fps41 × 31.1 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
MV-CS060-10GCArea camera3072 × 2048 px19.1 fps1/1.8″Gigabit Ethernet
MV-CA013-20GMArea camera1280 × 1024 px90 fps1/2″Gigabit Ethernet
MV-CA050-12UCArea camera2448 × 2048 px47 mono / 60 color fps2/3″USB3.0, compatible with USB2.0
MV-CE060-10UCArea camera3072 × 2048 px42.7 fps1/1.8″USB3.0, compatible with USB2.0
MV-CE200-10UMArea camera5472 × 3648 px19.2 fps1″USB3.0, compatible with USB2.0
MV-CU013-80UMArea camera1280 × 1024 px240.4 fps1/2.7″USB3.0, compatible with USB2.0
MV-CU020-90GCArea camera2048 × 1200 px49 fps—Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CH120-10GMArea camera4096 × 3000 px9.9 fps—Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
MV-CH120-10UCArea camera4096 × 3000 px30.5 fps1.1″USB3.0, compatible with USB2.0
MV-CH250-60GMArea camera5120 × 5120 px4.7 fps12.6 × 12.6 mmGigabit Ethernet
MV-CH050-60UMArea camera2448 × 2048 px79 fps2/3″USB 3.0, compatible with USB 2.0
MV-CH650-60TM-M58S-NNArea camera9344 × 700817.5 fps @9344 × 700830 × 22.4 mm10 Gigabit Ethernet (10000 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s)
