Industrial code reader · ID7000 series
Hikrobot MV-ID7080EM-35F-WHA V3.0
7424 × 1 pxGigabit Ethernet35 mm
Price on requestAn engineer will confirm pricing and lead time in the first reply.
Specifications
| Resolution | 7424 × 1 px |
| Mono color | Mono |
| Data interface | Gigabit Ethernet |
| Digital I/O | 10-pin green terminal; differential input ×1, opto-isolated input ×1, opto-isolated output ×2, RS-232 ×1 |
| Lens mount | F-mount |
| Focal length | 35 mm |
| Power supply | 48 VDC |
| Operating temperature | 0 °C to 50 °C |
| Storage temperature | -30 °C to 70 °C |
| Humidity | 20% to 95% RH, non-condensing |
| Dimensions | 608.3 mm × 127.6 mm × 167.1 mm |
| Weight | 5 kg |
| Symbologies | Code 39, Code 93, Code 128, CodaBar, EAN 8, EAN 13, ITF 14, ITF 25, UPCA, UPCE, QR Code, Data Matrix |
| Max. line frequency | 15 kHz |
| Max. operating speed of conveyer belt | 2.5 m/sec |
| Best working distance | 1000 mm |
| Field of view (range) | 1000 mm @10 mil |
| Communication protocol | SmartSDK, TCP Client, Serial, FTP, TCP Server |
| Max. power consumption | 180 W @ 48 VDC |
| Flange back focal length | 46.5 mm |
