FA lens · HF-E series
Hikrobot MVL-HF1628M-6MPE
16 mm
Price on requestAn engineer will confirm pricing and lead time in the first reply.
Specifications
| Product type | Fixed focal length, Manual iris, 6MP, FA Lens |
| Mount | C-mount |
| Focal length | 16 mm |
| Aperture | F2.8 to F16 |
| Image circle | Ø 9 mm (1/1.8’’) |
| Minimum object distance (MOD) | 0.1 m |
| Operating temperature | –10 °C to 50 °C |
| Dimensions | Ø 33 mm × 31.9 mm |
| Weight | 56.1 g |
| Certification | RoHS 2.0 |
| Distortion | -0.018 % |
| Field of view diagonal | 31.28 ° |
| Field of view horizontal | 25.94 ° |
| Field of view vertical | 17.48 ° |
| Filter thread | M27 × P0.5 |
| Flange back length | 17.526 mm |
| Focus control | Manual |
| Iris control | Manual |
