FA lens · MF series
Hikrobot MVL-MF2528M-10MPE
25 mm
Price on requestAn engineer will confirm pricing and lead time in the first reply.
Specifications
| Mount | C-mount |
| Focal length | 25 mm |
| Aperture | F2.8 to F16 |
| Image circle | Φ11.2 mm (2/3″) |
| Minimum object distance (MOD) | 0.15 m |
| Operating temperature | –10 °C to 50 °C |
| Dimensions | Φ29 mm × 29.28 mm (Φ1.1″ × 1.2″) |
| Weight | 46 g |
| Certification | RoHS 2.0 |
| Distortion | –0.48% |
| Field of view diagonal | 22.81 ° |
| Field of view horizontal | 17.12 ° |
| Field of view vertical | 14.14 ° |
| Iris control | Manual |
| Focus control | Manual |
| Filter thread | M27 × P0.5 |
| Flange back length | 17.526 mm |
